Audio-Technica AT-VM95SH VM95 Series Shibata Stereo Cartridge
Audio-Technica AT-VM95SH VM95 Series Shibata Stereo Cartridge
Sale price£189.99
Product Overview
The AT-VM95SH, features a Nude Shibata stylus, one of the most acclaimed stylus format by high end audiophiles.
The Shibata stylus produces mid and bass sounds strong and rich in addition to offer a frequency response up to 25,000 Hz.
FEATURES
-
Aluminium Cantilever: Provides durability and precise tracking for accurate playback of your vinyl records.
-
3.5mV Output Voltage: Delivers a robust output signal, ensuring clear and dynamic sound reproduction.
-
Compatible Body with all VM95 Series Stylus Assemblies: Offers versatility and convenience, allowing you to interchange stylus assemblies to suit your audio preferences.
- 20 to 25,000Hz Frequency Response: Provides an extended frequency range, capturing a wide spectrum of audio frequencies for lifelike sound reproduction.
Specifications
- Model: AT-VM95SH
- Type: VM Stereo Dual Magnet
- Mounting: 1/2” centres
- Frequency Response: 20 - 25,000 Hz
- Channel Separation: 23 dB (1 kHz)
- Output Channel Balance: 1.5 dB (1 kHz)
- Output Voltage: 3.5 mV (@ 1 kHz, 5 cm/sec)
- Vertical Tracking Angle: 23°
- Vertical Tracking Force Range: 1.8 - 2.2g (standard 2.0 g)
- Stylus Shape: Shibata
- Stylus Size: 2.7 x 0.26mil
- Stylus Construction: Nude Square Shank
- Cantilever: Aluminium Pipe
- Coil Impedance: 3.3 kΩ (1 kHz)
- Coil Inductance: 550 mH (1 kHz)
- DC Resistance: 485 Ω
- Static Compliance: 20 x 10 – 6 cm / dyne
- Dynamic Compliance: 10 x 10 – 6 cm / dyne (100 Hz)
- Wire Used for Coil: T.P. Copper
- Recommended Load Impedance: 47,000 Ω
- Recommended Load Capacitance: 100-200 pF
- Cartridge Weight: 6.1g
- Dimensions: 17.2 x 18.9 x 28.3 ( H x W x D mm)
- Replacement Stylus: AT-VMN95SH
